LK956 Grain Loader | U & Me Traders Pakistan
The LK956 Grain Loader is a high-capacity, heavy-duty machine purpose-built for grain storage facilities, feed mills, bulk material yards, and agricultural logistics. Designed with a large grain bucket, reinforced boom arms, and a powerful diesel engine, the LK956 delivers maximum efficiency in moving light bulk materials over long hours of operation.
Technical Specifications – LK956 Loader
| Specification | Details |
|---|---|
| Model | LK956 Grain Loader |
| Rated Load Capacity | 5,000 – 5,500 kg (5–5.5 tons) – Handles heavy grain and bulk loads |
| Operating Weight | Approx. 16,800 kg – Built for rugged terrain and continuous operation |
| Engine Options | Weichai / Cummins 6-cylinder turbocharged diesel |
| Rated Power Output | 162–178 kW (220–240 hp) – Delivers superior torque and fuel efficiency |
| Grain Bucket Capacity | 4.0 – 5.5 m³ – Designed for light, high-volume materials like wheat, corn |
| Transmission Type | Power shift hydraulic transmission with planetary gears |
| Gear System | 4 Forward / 4 Reverse |
| Dumping Height | 3,200 – 3,500 mm – Suitable for truck beds, hoppers, and grain silos |
| Max Lifting Height | 4,200 mm – Supports tall bin and storage facility operations |
| Steering System | Full hydraulic articulated steering |
| Brake System | Air-over-oil disc brakes with emergency brake system |
| Tire Size | 23.5/25 – Deep tread for heavy ground conditions |
| Cab Features | ROPS/FOPS-certified enclosed cab, A/C, ergonomic seat |
| Optional Attachments | Standard bucket, log grab, bale clamp, snow blade, pallet fork |
Working Mechanism – How the LK956 Grain Loader Operates
The LK956 loader operates with a powerful hydraulic transmission system coupled with a high-output diesel engine. It transfers engine power efficiently into the drivetrain and lift system using a power shift gearbox, offering smooth transitions between forward and reverse gears, even under load.
Its oversized grain bucket is engineered for light, loose materials such as grains, soybeans, fertilizer, sawdust, or corn husk, ensuring maximum load capacity with minimal spillage. The articulated steering design and wide wheelbase make it highly stable when operating in tight grain storage yards or silo loading zones.
Operators benefit from joystick-controlled hydraulics inside a fully enclosed cabin that offers unobstructed visibility, essential for safe and efficient bulk material loading.
Advantages of the LK956 Grain Loader
🔹 Massive Grain Bucket Reduces Loading Cycles
With a 5.5 m³ bucket, the LK956 handles more volume in fewer passes—ideal for grain elevators, bulk terminals, and feed plants.
🔹 Reliable High-Torque Engine for Heavy-Duty Loads
Powered by a Weichai or Cummins diesel engine, the loader offers high torque output and fuel efficiency, reducing downtime and operating costs.
🔹 Optimized for Agricultural Bulk Handling
The loader’s grain-specific configuration makes it perfect for loose, lightweight materials like wheat, corn, rice bran, and fertilizer, with less wear and more productivity.
🔹 Operator Comfort with Enclosed Climate-Controlled Cab
The ROPS/FOPS-certified cabin features A/C, wide visibility windows, a suspension seat, and low-vibration design—keeping the operator comfortable and focused during long shifts.
🔹 High Dump and Lift Height for Grain Infrastructure
With over 4,200 mm of lift height, the LK956 is tailored for filling tall hoppers, loading silos, and transferring material into long-bed trailers.
🔹 Durable Construction and Low Maintenance
Heavy-duty axles, a reinforced frame, and easy-access service points make the LK956 a long-lasting investment for commercial grain handling operations.
🔹 Multi-Purpose Loader with Quick Attachment System
Beyond grain, the LK956 can be used year-round with attachments for log grappling, snow plowing, pallet movement, or loading bales—making it a versatile farm and industrial loader.
Order the LK956 Grain Loader from U & Me Traders Today
Whether you're scaling up your grain facility or need a reliable farm loader for daily operations, U & Me Traders is your trusted supplier of quality wheel loaders in Pakistan. Contact us now to get specifications, pricing, and delivery options for your region.
