928F Wheel Loader | U & Me Traders Pakistan
The 928F Wheel Loader is engineered for operators who need a high-capacity, mid-size machine with the toughness and reliability for construction, quarrying, agricultural, and industrial applications. With a powerful diesel engine, robust lifting arms, and quick-attach compatibility, the 928F stands out as a 2.8-ton loader that delivers on every job site.
Technical Specifications – 928F Loader
| Specification | Details |
|---|---|
| Model | 928F Wheel Loader |
| Rated Load Capacity | 2,800 kg (2.8 tons) – Ideal for medium to heavy material handling tasks |
| Operating Weight | Approx. 5,800–6,200 kg – Ensures balance and traction in all terrains |
| Engine Options | Yunnei 4102 / Xinchai 490 / Cummins optional |
| Rated Power Output | 55–76 kW (75–102 hp) – Delivers high torque with fuel efficiency |
| Bucket Capacity | 1.0 – 1.2 m³ – Suitable for gravel, sand, feed, construction debris |
| Transmission Type | Hydraulic torque converter |
| Gears | 4 Forward / 4 Reverse |
| Dumping Height | 3,200 mm – Effective for loading into mid-size trucks and containers |
| Max Lifting Height | 3,500 mm – Supports stacking and elevated tipping |
| Steering System | Full hydraulic articulated steering |
| Brake System | Air-over-oil disc brakes |
| Tire Size | 20.5/70-16 or 16/70-20 heavy-duty radial tires |
| Cabin Features | ROPS/FOPS enclosed cab, ergonomic seat, optional air conditioning |
| Supported Attachments | Pallet forks, log grapple, snow blade, auger, bale clamp |
Working Mechanism – How the 928F Loader Operates
The 928F loader features a hydraulic torque converter transmission system that channels diesel engine power into smooth, controlled motion across the wheels and boom arms. Its articulated frame offers excellent maneuverability on job sites with limited space or rough terrain.
Inside the enclosed operator cabin, joystick-controlled hydraulics allow for precision lifting, tilting, and attachment use. From earthmoving and bulk loading to snow removal or grain transport, the 928F offers efficient cycle times, responsive operation, and enhanced visibility.
The loader is optimized for use in construction yards, warehouses, grain terminals, and road maintenance, making it one of the most flexible machines in its class.
Advantages of the 928F Wheel Loader
🔹 Powerful Mid-Size Performance
With a 2.8-ton rated capacity, the 928F handles a wide range of tasks—from bulk material transport to industrial cleanup—with ease and stability.
🔹 Fuel-Efficient Engine Options
The loader’s Yunnei, Xinchai, or optional Cummins diesel engines are known for high torque, low emissions, and long-lasting reliability—making the 928F a cost-effective solution for fleet operators.
🔹 Quick-Attach System for Multi-Functionality
Operators can switch between buckets, grapples, forks, and more in minutes, turning the 928F into a multi-purpose loader across industries and seasons.
🔹 Enhanced Dumping and Reach Capabilities
With a 3.2-meter dump height and 3.5-meter lift capacity, the machine can efficiently handle truck loading, bin filling, or elevated stacking jobs.
🔹 Operator Comfort and Safety
The ROPS/FOPS-certified cab includes ergonomic seating, climate control (optional), and wide-angle visibility—ideal for long working shifts in any weather.
🔹 Low Maintenance with Long Life Components
Designed with heavy-duty axles, reinforced loader arms, and easy-access service ports, the 928F is built to reduce downtime and maximize uptime.
